Basic Values of Thermoelectric Voltage in mV
What is the thermoelectric voltage of a type K or type J thermocouple?
In the table below you will find the thermoelectric voltage in mV for all thermocouple types. The thermoelectric voltage (in millivolts mV) for a type K thermocouple, for example, at a temperature of 300/°C is equal to 12.209 mV. The thermoelectric voltage at type J and a temperature of 300/°C is equal to 16.327 mV. The complete overview for all pairs and temperatures from -100 °C to +1700 °C can be found in the following table.
Thermoelectric voltage in mV with reference to a cold junction temperature of 0°C:
| thermocouple: | type K | type L | type J | type U | type T | type E | type N | type S | type R | type B |
temperature t 90/°C | +NiCr -Ni | +Fe -CuNi | +Fe -CuNi | +ECu -CuNi | +ECu -CuNi | +NiCr -CuNi | +NiCrSi -NiSi | +PtRh 10 -Pt | +PtRh 13 -Pt | +PtRh 30 -PtRh 6 |
| DIN EN 60584 | *DIN 43710 | DIN EN 60584 | *DIN 43710 | DIN EN 60584 | DIN EN 60584 | DIN EN 60584 | DIN EN 60584 | DIN EN 60584 | DIN EN 60584 | |
| -100 | -3,554 | -4,75 | -4,633 | -3,40 | -3,379 | -5,237 | -2,407 | - | - | - |
| 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 100 | 4,096 | 5,37 | 5,269 | 4,25 | 4,279 | 6,319 | 2,774 | 0,646 | 0,647 | 0,033 |
| 200 | 8,138 | 10,95 | 10,779 | 9,20 | 9,288 | 13,412 | 5,913 | 1,441 | 1,469 | 0,178 |
| 300 | 12,209 | 16,56 | 16,327 | 14,90 | 14,862 | 21,036 | 9,341 | 2,323 | 2,401 | 0,431 |
| 400 | 16,397 | 22,16 | 21,848 | 21,00 | 20,872 | 28,946 | 12,974 | 3,259 | 3,408 | 0,787 |
| 500 | 20,644 | 27,85 | 27,393 | 27,41 | - | 37,005 | 16,748 | 4,233 | 4,471 | 1,242 |
| 600 | 24,905 | 33,67 | 33,102 | 34,31 | - | 45,093 | 20,613 | 5,239 | 5,583 | 1,972 |
| 700 | 29,129 | 39,72 | 39,132 | - | - | 53,112 | 24,527 | 6,275 | 6,743 | 2,431 |
| 800 | 33,275 | 46,22 | - | - | - | 61,017 | 28,455 | 7,345 | 7,950 | 3,154 |
| 900 | 37,326 | 53,14 | - | - | - | 68,787 | 32,371 | 8,449 | 9,205 | 3,957 |
| 1000 | 41,276 | - | - | - | - | 76,373 | 36,256 | 9,587 | 10,506 | 4,834 |
| 1100 | 45,119 | - | - | - | - | - | 40,087 | 10,757 | 11,850 | 5,780 |
| 1200 | 48,838 | - | - | - | - | - | 43,846 | 11,951 | 13,228 | 6,786 |
| 1250 | 50,644 | - | - | - | - | - | 45,694 | 12,554 | 13,926 | 7,311 |
| 1300 | 52,410 | - | - | - | - | - | 47,513 | 13,159 | 14,629 | 7,848 |
| 1400 | - | - | - | - | - | - | - | 14,373 | 16,040 | 8,956 |
| 1450 | - | - | - | - | - | - | - | 14,978 | 16,746 | 9,524 |
| 1500 | - | - | - | - | - | - | - | - | - | 10,099 |
| 1600 | - | - | - | - | - | - | - | - | - | 11,263 |
| 1700 | - | - | - | - | - | - | - | - | - | 12,433 |
*Since April 1994 the standard DIN 43710 is no longer valid
