T425
Flange protecting armature for gauge slides Ø 6 mm
Flange protecting armature for gauge slides Ø 6 mm
Construction
| Protecting tube form FS with tapered measuring tip (quick response time) | - 1.4571 Ø 11 x 2 mm - 1.4571 Ø 11 x 2 mm - Halar® - coating |
|---|---|
| Gauge slide | - without gauge slide - with gauge slide - acc. to customer’s request |
| Flange | - DN 20 PN 40 DIN EN 1092-1 - DN 25 PN 40 DIN EN 1092-1 - DN 40 PN 40 DIN EN 1092-1 - DN 50 PN 40 DIN EN 1092-1 |
| Connection head | - B (KE 122) - DAN-WZ (KE 202) - DAN-Z (KE 064) - DAN-WS (KE 204) - DAN-S (KE 066) - BNK (KK 029) - without connection head - other connection head - acc. to customer’s request |
| Inset / neck tube / immersion length | - 100/120/255 mm - 160/120/315 mm - 250/120/405 mm - 400/120/555 mm - other length - acc. to customer’s request |
- 1.4571 Ø 11 x 2 mm
- 1.4571 Ø 11 x 2 mm - Halar® - coating
- without gauge slide
- with gauge slide - acc. to customer’s request
- DN 20 PN 40 DIN EN 1092-1
- DN 25 PN 40 DIN EN 1092-1
- DN 40 PN 40 DIN EN 1092-1
- DN 50 PN 40 DIN EN 1092-1
- B (KE 122)
- DAN-WZ (KE 202)
- DAN-Z (KE 064)
- DAN-WS (KE 204)
- DAN-S (KE 066)
- BNK (KK 029)
- without connection head
- other connection head - acc. to customer’s request
- 100/120/255 mm
- 160/120/315 mm
- 250/120/405 mm
- 400/120/555 mm
- other length - acc. to customer’s request
