T402

Thermometer with 1 transmitter in the cap without additional protecting tube form MK

Thermometer with 1 transmitter in the cap without additional protecting tube form MK

Thermometer with 1 transmitter in the cap without additional protecting tube form MK

Construction

Connection head

- DAN-WZ (KE 202)

- DAN-WS (KE 204)

- other connection head - acc. to customer’s request

Ø sheath / measuring tip

- 3.0/3.0 mm

- 6.0/8.0 mm

- 4.5/4.5 mm

- 6.0/4.0 mm

- 6.0/6.0 mm

- 8.0/8.0 mm

- other diameters - acc. to customer’s request

Gauge slide

- without gauge slide

- with gauge slide - acc. to customer’s request

Inset length

- 255 mm

- 275 mm

- 290 mm

- 315 mm

- 340 mm

- 375 mm

- 405 mm

- 430 mm

- 435 mm

- 525 mm

- 555 mm

- 580 mm

- 655 mm

- 735 mm

- 825 mm

- 1025 mm

- 1275 mm

- 1425 mm

- 1625 mm

- 1825 mm

- 2025 mm

- 2425 mm

- 3025 mm

- other length - acc. to customer’s request

Connection head

- DAN-WZ (KE 202)

- DAN-WS (KE 204)

- other connection head - acc. to customer’s request

Ø sheath / measuring tip

- 3.0/3.0 mm

- 6.0/8.0 mm

- 4.5/4.5 mm

- 6.0/4.0 mm

- 6.0/6.0 mm

- 8.0/8.0 mm

- other diameters - acc. to customer’s request

Gauge slide

- without gauge slide

- with gauge slide - acc. to customer’s request

Inset length

- 255 mm

- 275 mm

- 290 mm

- 315 mm

- 340 mm

- 375 mm

- 405 mm

- 430 mm

- 435 mm

- 525 mm

- 555 mm

- 580 mm

- 655 mm

- 735 mm

- 825 mm

- 1025 mm

- 1275 mm

- 1425 mm

- 1625 mm

- 1825 mm

- 2025 mm

- 2425 mm

- 3025 mm

- other length - acc. to customer’s request
