Robot multibus cable

2 x (2 x 0,25mm²) D + 2 x (2 x 0,34mm²) D + 1,0 + (2 x 0,29mm²) D + 2 x (2 x 1,0mm²) D

Robot multibus cable

Robot multibus cable

Construction

Conductor

bare resp. tinned copper strands

acc. to IEC 60228

Sheath material

PUR, TMPU

acc. to EN 50363-10-2 + VDE 0207-363-10-2

Sheath colour

redlilac (RAL 4001)

Conductor

bare resp. tinned copper strands

acc. to IEC 60228

Sheath material

PUR, TMPU

acc. to EN 50363-10-2 + VDE 0207-363-10-2

Sheath colour

redlilac (RAL 4001)

Technical data

Operating voltage

max. 350 V

Voltage UL

30 V

Testing voltage

core/core 1000 V

core/screen 700 V

Temperature range

flexible application:

-40/+70 °C

UL: up to +80 °C

Min. bending radius

recommended: 12 x d a

Absence of harmful substances

acc. to RoHS directive of the European Union

Operating voltage

max. 350 V

Voltage UL

30 V

Testing voltage

core/core 1000 V

core/screen 700 V

Temperature range

flexible application:

-40/+70 °C

UL: up to +80 °C

Min. bending radius

recommended: 12 x d a

Absence of harmful substances

acc. to RoHS directive of the European Union

Dimensions

item no. Dimension Outer-ø
L0726-00432 x (2 x 0,25 mm²) D + 2 x (2 x 0,34 mm²) D + 1,0 mm² + (2 x 0,29 mm²) D + 2 x (2 x 1,0 mm²) D13,9 mm Send inquiry
item no.
Dimension
Outer-ø
L0726-0043
2 x (2 x 0,25 mm²) D + 2 x (2 x 0,34 mm²) D + 1,0 mm² + (2 x 0,29 mm²) D + 2 x (2 x 1,0 mm²) D
13,9 mm

Other dimensions and colours are possible on request.
