GP 400 SC DC

Ground Power supply cable 28 V DC - SingleCore Direct Current

Marking example: SAB BRÖCKSKES · D-Viersen · GP 400 SC DC (120,0mm²+4x1,0mm²) 3400-1621 and continuous meter marking

Marking example: SAB BRÖCKSKES · D-Viersen · GP 400 SC DC (120,0mm²+4x1,0mm²) 3400-1621 and continuous meter marking

Application

For use in flexible applications, e.g. mobile generators, cable dispensers in the ground or on the passenger bridge at 28 V DC.

Outstanding features

  • abrasion-resistant PUR jacket
  • control cores symmetrically arranged
  • cold flexible
  • halogene free
  • oil resistant
  • weather resistant

Construction

Conductor

tinned copper strands

Insulation

SABIX®

Colour code

control cores: red, black, green, yellow

power supply core: red

Stranding

control cores within the power supply core

Sheath material

PUR

Sheath colour

orange

Conductor

tinned copper strands

Insulation

SABIX®

Colour code

control cores: red, black, green, yellow

power supply core: red

Stranding

control cores within the power supply core

Sheath material

PUR

Sheath colour

orange

Technical Data

Voltage

28 V DC

Testing voltage

core/core 600 V AC

Min. bending radius

fixed laying: 4 x d

flexible application: 6 x d

Temperature range

fixed laying: -50/+90 °C

flexible application: -40/+90 °C

limited time of use: +110 °C (7500 h)

Halogen-free

acc. to IEC 60754-1 + VDE 0482-754-1

Oil resistance

very good - TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2

Weather resistance

very good

Absence of harmful substances

gemäß RoHS-Richtlinie der Europäischen Union

Voltage

28 V DC

Testing voltage

core/core 600 V AC

Min. bending radius

fixed laying: 4 x d

flexible application: 6 x d

Temperature range

fixed laying: -50/+90 °C

flexible application: -40/+90 °C

limited time of use: +110 °C (7500 h)

Halogen-free

acc. to IEC 60754-1 + VDE 0482-754-1

Oil resistance

very good - TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2

Weather resistance

very good

Absence of harmful substances

gemäß RoHS-Richtlinie der Europäischen Union

Reference value of current carrying capacity from derating curve

For 20°C ambient temperature, taken from 80% curve

500 A

For 20°C ambient temperature, taken from 100 % curve

600 A

Precondition

laying separately free in air

For 20°C ambient temperature, taken from 80% curve

500 A

For 20°C ambient temperature, taken from 100 % curve

600 A

Precondition

laying separately free in air

Dimensions

item no. No. of cores x
cross section
Approx. outer-ø Copper figure Cable weight ≈ Ohmic resistance
at 20°C max.
Voltage drop Outer-ø ± 5%
L340016211 x (120,00 mm² + 4 x 1,0 mm²)22,2 mm1296,0 kg/km1339 kg/km0,164 / 20,0 Ω/km0,328 / 40,0 [mV/(A*m)]22.2 Send inquiry
item no.
No. of cores x
cross section
Approx. outer-ø
Copper figure
Cable weight ≈
Ohmic resistance
at 20°C max.
Voltage drop
Outer-ø ± 5%
L34001621
1 x (120,00 mm² + 4 x 1,0 mm²)
22,2 mm
1296,0 kg/km
1339 kg/km
0,164 / 20,0 Ω/km
0,328 / 40,0 [mV/(A*m)]
22.2

Other dimensions and colours are possible on request.
