Customized cables and wires according to customer requirements

We develop and produce custom cables & wires as well as special solutions particularly according to your requirements and applications:

As versatile as the applications or functions of electrical cables are, the design of cables and wires must be adapted individually. That is why our claim is to develop and produce an individual cable according to your specifications for each customer and application.

In many cases, we manufacture special cables starting at 300 m, in certain dimensions already for 100 m. You can rely on over 75 years of experience in cable production, that our technical team will select the best combination of the several parameters for you and develop and produce an individual cable for your application:

Download: Special Cables from SAB Bröckskes

Flexible Cables and Wires “Made in Germany”

As a leading special cable manufacturer we develop and produce cables for industrial purposes. Our wide range of insulation and sheathing materials offers a lot of possibilities for your individual product requirement. The following survey shows an extract of our production possibilities:



Conductor Materials

What conductor materials are used for cables?

  • Bare copper
  • Tinned copper
  • Silver plated copper
  • Nickel plated copper
  • Nickel
  • Nickel pure
  • Compensating cable alloy


Shielding and Braiding Materials

Which materials are used for cable shielding/screening?

  • Bare copper
  • Tinned copper
  • Galvanized steel
  • Stainless steel
  • Aluminium foil
  • Fibreglass
  • Aramid


Conductors

Which wire cross-sections do we produce at SAB?

  • cross sections: 0,055 mm² - 300 mm²
  • variety of stranding styles

Number of cores

What is the max. number of cores used in one cable?

  • unshielded and shielded over 100 conductors

Insulation and Sheating Materials

Which insulating and sheathing materials are used for the production of cables?

Temperature Ranges (based on marterial)

For which temperature ranges the insulating and sheathing materials can be applied?

  • Thermoplastic Elastomers
    -50°C up to +145°C
  • SABIX®
    -50°C up to +220°C
  • Besilen®/Silicone
    -40°C up to +220°C
  • FEP, ETFE, PFA, PTFE
    -90°C up to +260°C
  • Fibreglass
    up to +600°C

Approbationen

Which norms or approvals can be confirmed for cables and wires?

UL, CSA, CE, EAC, VDE, HAR, IEC, EN, ISO, DNV, LR, ABS, RINA, BSI

Further approvals can be offered according to customer requirements.

Cable labeling according to customer requirements

At the customer's request, we can print or label cables and wires according to your individual specifications and wishes. Individual cable marking or cable labeling can significantly simplify the handling of electrical cables. With your own cable labeling, you can also implement your own branding and highlight your own brand. In many cases, we can produce individual cables with labeling from a length of 300 m. Contact us directly.
